Manometer dry metal radial

Pressure gauges - dry metal radial

Application: Suitable for all gaseous and liquid media that will not obstruct the pressure system or attack copper alloy parts. Useful for system that are not submited to strong vibrations. Specialy designed for pneumatics and hydraulics.

Case material: Steel painted black
Display: Acrylic
Case closing: Adjusted
Class: 2.5 (Ø63-75)/ 1.6 (Ø100)
Scale: bar/psi
Moving parts material: Copper alloy
Elastic element: Bourdon tube
Thread material: Brass
IP protection: IP 44

Article No.	Price (pcs.)	Quantity (pcs.)	DN	Pressure bar
3521300210	9,56 €		63 - 1/4	-1 + 0
3521300410	9,56 €		63 - 1/4	-1 + 0,5
3521300610	9,56 €		63 - 1/4	-1 + 1,5
3521300810	9,56 €		63 - 1/4	-1 + 3
3521301010	9,56 €		63 - 1/4	-1 + 5
3521301210	9,56 €		63 - 1/4	-1 + 9
3521301410	9,56 €		63 - 1/4	-1 + 15
3521301610	9,56 €		63 - 1/4	-1 + 24
3521301810	9,56 €		63 - 1/4	0 + 0,6
3521302010	9,56 €		63 - 1/4	0 + 1
3521302210	9,56 €		63 - 1/4	0 + 1,6
3521302410	9,56 €		63 - 1/4	0 + 2,5
3521302610	9,56 €		63 - 1/4	0 + 4
3521302810	9,56 €		63 - 1/4	0 + 6
3521303010	9,56 €		63 - 1/4	0 + 10
3521303110	9,56 €		63-1/4	0 +12
3521303210	9,56 €		63 - 1/4	0 + 16
3521303410	9,56 €		63 - 1/4	0 + 25
3521303610	9,56 €		63 - 1/4	0 + 40
3521303810	9,56 €		63 - 1/4	0 + 60
3521304010	9,56 €		63 - 1/4	0 + 100
3521304210	9,56 €		63 - 1/4	0 + 160
3521304410	9,56 €		63 - 1/4	0 + 250
3521304610	9,56 €		63 - 1/4	0 + 315
3521304810	9,56 €		63 - 1/4	0 + 400
3521305010	31,87 €		63 - 1/4	0 + 600
3521305210	31,87 €		63 - 1/4	0 + 1000
3521500210	19,12 €		100 - 1/2	-1 + 0
3521500410	19,12 €		100 - 1/2	-1 + 0,5
3521500610	19,12 €		100 - 1/2	-1 + 1,5
3521500810	19,12 €		100 - 1/2	-1 + 3
3521501010	19,12 €		100 - 1/2	-1 + 5
3521501210	19,12 €		100 - 1/2	-1 + 9
3521501410	19,12 €		100 - 1/2	-1 + 15
3521501610	19,12 €		100 - 1/2	-1 + 24
3521501810	19,12 €		100 - 1/2	0 + 0,6
3521502010	19,12 €		100 - 1/2	0 + 1
3521502210	19,12 €		100 - 1/2	0 + 1,6
3521502410	19,12 €		100 - 1/2	0 + 2,5
3521502610	19,12 €		100 - 1/2	0 + 4
3521502810	19,12 €		100 - 1/2	0 + 6
3521503010	19,12 €		100 - 1/2	0 + 10
3521503210	19,12 €		100 - 1/2	0 + 16
3521503410	19,12 €		100 - 1/2	0 + 25
3521503610	19,12 €		100 - 1/2	0 + 40
3521503810	19,12 €		100 - 1/2	0 + 60
3521504010	19,12 €		100 - 1/2	0 + 100
3521504210	19,12 €		100 - 1/2	0 + 160
3521504410	21,95 €		100 - 1/2	0 + 250
3521504610	21,95 €		100 - 1/2	0 + 315
3521504810	21,95 €		100 - 1/2	0 + 400
3521505010	49,57 €		100 - 1/2	0 + 600
3521505210	-	-	100 - 1/2	0 + 1000
